ADA208PH

INPUT

• CONNECTORS - 2 each PHX

• INPUT TYPE - Active balanced with RFI filtering

• INPUT AUDIO LEVEL - Adjustable - 10 dBu to +4 dBu

• MAX INPUT LEVEL - + 26 dBu

• INPUT IMPEDANCE - >10K Ohms (balanced)

• INPUT CCMR - 60 dB at 60 Hz

• GAIN - 20 dB Max

• NOMINAL LEVEL - + 4 dBu input/output

• PEAK LEVELS - + 26 dBu input and + 26 dBu output

OUTPUTS

• NUMBER OF OUTPUTS 8 each PHX

• OUTPUT LEVEL + 4dBu

• MAX OUTPUT LEVEL + 26 dBu

• OUTPUT IMPEDANCE < 40 Ohms

• OUTPUT GAIN ADJUST + 8 dB to - 10 dB for each output

• OUTPUT PROTECTION Short circuit protection on each output

• FREQUENCY RESPONSE +/- 0.1 20 Hz to 20 kHz

• THD DISTORTION AT +4 DB 0.01% 20 Hz to 20 kHz

• THD DISTORTION AT MAXIMUM LEVEL 0.1% 20 Hz to 20 kHz

• IMD DISTORTION SMPTE 0.05%

• SIGNAL TO NOISE RATIO > 90 dB 20 Hz to 22 kHz

• INTER CHANNEL LEVEL DIFFERENCE > 0.5db 20 Hz to 20KHz

• INTER CHANNEL PHASE DIFFERENCE < 0.5 degrees 20 Hz to 20 kHz

• INTER CHANNEL CROSSTALK > 90 db 20Hz to 20KHz

• SLEW RATE 13 volts per microsecond

ELECTRO MAGNETIC INTERFERENCE (EMI) Unit is intrinsically EMI proof

POWER Auto-sensing 110-240 VAC +/- 10% 47 to 63 Hz, 20 VA

SIZE 19" (48.3 cm) W x 1.75" (4.4 cm) H x 7.5" (19cm) H

WEIGHT 5 lbs. (2.3 kg) net shipping weight

WARRANTY Limited One Year
